SABIK provide a range of quality domestic MVHR units with low consumption EC motors and high efficiency counterflow heat exchangers available both in sensible and enthalpy -E- versions (up to 92% sensible recovery, and up to 82% latent recovery).
The units assure a continuous and balanced ventilation system, extracting moist stale air from the wet rooms and at the same time introducing a tempered and filtered fresh air to the habitable rooms.
The optimised design allows compliance with the highest standards assuring a very low leakage level, high thermal insulation and a minimal sound level.
The integrated humidity sensor allows an automatic function tracking the indoor humidity and proportionally adjusting the fans speed.
The unit contains as a standard iso coarse 65% (G4) filters in the supply and extract airflows to clean the incoming air and protect the heat exchanger.
For higher air quality an optional Pm1 70% (F7) filter can be installed in the supply air channel.
An integrated 100% bypass is activated either automatically or manually.
The bypass is particularly useful when the indoors temperature is higher than outdoors and free cooling is preferable.
INSTALLATION FRIENDLY
A versatile product with advantages for installation.
The airflow direction paths can be handed to allow for alternate on-site configurations of duct routing.
A range of accessories lets the end user tailor the functions of the system to their specific requirements.
Characteristics:
-High efficiency counterflow heat exchangers available in sensible and enthalpy -E- versions.
-Low consumption EC motors
-Minimal sound level
-Automatic/manual bypass
-Install friendly
-User friendly
-Customisable
Optional accessories:
-Integrable pre heater
-Integrable VOC sensor
-Communication module
-Integrable constant airflow module (Servoflow)
